Technical Parameters:
· AC Voltage: AC 100V-220V 50/60HZ
· POE Voltage: DC 48-52V
· POE Protocol: IEEE 803.af
· Maximum Power Consumption: 25W
· Network Protocols: MA-NET1, MA-NET2, SACN, Art-Net, RDM
· Compatible Protocols: MA2 lighting console, grandMA2 onPC, and digital lighting consoles supporting Art-Net
· Communication Parameters: Connect to PC emulators, physical consoles; decodes up to 1024 channels
· Signal Channels: Two-way DMX512 inputs or outputs (customizable)
· Display: LCD English menu
· Setup Method: Software-based
· Dimensions: 170 x 145 x 38 mm (rack-mountable)
